the signet 2537 flow sensor is the next generation in fluid measurement technology from the inventor of the original paddlewheel flowmeter. this sensor is an enhancement on what's already an industry standard.
manufacturer: georg fischer ltd

the signet 2537 flow sensor is the next generation in fluid measurement technology from the inventor of the original paddlewheel flowmeter. this sensor is an enhancement on what's already an industry standard. it has the added functionality of various output options including flow switch, pulse divider, digital (s3l) or 4 to 20 ma. additionally, it offers low flow, low power and high resolution and can be configured on-site directly through the built-in user interface.

installation is simple because the signet 2537 utilizes the same fittings as the popular signet 515 and 2536 paddlewheel sensors, and fits into pipe sizes ranging from dn15 to dn200 (½ to 8 in.). available in polypropylene and pvdf, it is ideal for a variety of applications including chemical processing, water and wastewater monitoring and scrubber control.


flow:

  • installs into pipe sizes: dn15 to dn200, 0.5 to 8 in
  • operating range: 0.1 to 6 m/s, 0.3 to 20 ft/s
  • outputs: digital s3l, 4 to 20ma or multi-function
  • max pressure rating: pp 12.5 bar @ 20 °c, 180 psi @ 68 °f pvdf 14 bar @ 20 °c, 200 psi @ 68 °f
  • power source: digital - 5 vdc nominal, relay & 4-20 ma - 24 vdc nominal
  • compatibility: 8550, 8900, 9900, 9900-1bc
  • rotor: pvdf

advantages:

  • low flow capabilities down to 0.1 m/s (0.3 ft/s)
  • allows up to six connections to signet 8900 controller
  • low power and high resolution options
  • available with polypropylene and pvdf
  • digital (s3l) and 4 to 20 ma outputs
  • test certificate included for -x0, -x1
  • installs into pipe sizes dn15 to dn200 (½ to 8 in.)

fields of application:

  • chemical production
  • reverse osmosis
  • process flow monitoring
  • fume scrubbers
  • demineralization/regeneration
  • pump protection
  • filtration systems
  • pure water production
  • cooling towers

standards:

  • ce
  • ul
  • china rohs
  • rohs compliant
  • fcc
